PEEK (GF30) Hex Socket-Cylinder Head Cap Screw - DIN 912

728 In Stock
SKU: PKGFSH205
$1.91 - $2.94 CAD / each
Sale $6.91 CAD $1.91 - $2.94 CAD

Volume Discounts Available:

1 pc $2.94
20 pcs $2.79
50 pcs $2.65
100 pcs $2.35
250 pcs $2.21
500 pcs $2.06
1000 pcs $1.91
2000+ pcs Contact us
Show more Show less
Want it by XYZ?
Want it by XYZ?

Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom left of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080

Instant Quote:
Submit a request for quote online by clicking the button below and a PDF quotation will be delivered to your inbox within 5 mins.

Request a Quote

Material: PEEK GF30

Measurement System: Metric

Drive Type: Hex Socket

Colour: Natural/Beige

Continuous use temperature: 260°C/500°F

Flammability: UL94 V-0

PEEK (GF30) Hex Socket-Cylinder Head Cap Screw - DIN 912 conform to the following Standards/Norms:

ISO 4762

DIN 912

CSN 021143

PN 82302

UNI 5931

Socket Cap head screws meet the ultimate material makeup, 30% glass fibre reinforced PEEK.

Socket type screws allow for a multitude of applications due to the fastening type, drive type and strength. Our standard PEEK socket screws are very popular as they comply with DIN912 Specification. The PEEK GF30 material does not change this and provides added tensile strength to meet the most demanding applications.

6 point hexagonal drive comes as standard, the size chart can be seen above.

As with all our other fasteners, The PEEK GF30 Socket Cap Head Screws can be modified in house to meet your applications requirements, whether this is cutting or allowing ventilation, we strive to meet your needs.

What are PEEK (GF30) Socket Cap Head Screws and where are they used?

PEEK (polyetheretherketone) is a high performance polymer that is known for its exceptional mechanical strength, chemical resistance, and temperature resistance. "GF30" refers to the fact that the PEEK material has been reinforced with 30% glass fibers, which increases its strength and stiffness. A socket cap head screw is a type of fastener with a cylindrical head and a hexagonal socket in the center, designed to be driven with a hexagonal key or Allen wrench.

PEEK (GF30) socket cap head screws are therefore fasteners made of a PEEK polymer reinforced with 30% glass fibers, with a socket cap head design. These screws may be used in a wide range of applications where high strength and temperature resistance are required, including the following:

  1. Aerospace and defense industry
  2. Automotive and transportation industry
  3. Chemical processing and oil and gas industry
  4. Medical and surgical devices
  5. Consumer electronics and other high-tech applications
  6. Industrial piping and tubing
  7. Food processing and packaging equipment
  8. Bearings and bushings
  9. Seals and gaskets
  10. Electrical insulation materials
  11. Robotics and automation systems
  12. High-performance sporting goods
  13. Racing and high-performance vehicle parts
  14. Marine and shipbuilding applications
  15. Structural materials for bridges and buildings
  16. Telecommunications infrastructure
  17. Water treatment and filtration systems
  18. Pump and valve components

The PEEK GF30 data sheet is available as a PDF to download below.

Return components within 90 days for a full refund. Please see returns terms and conditions for further information.

PEEK (GF30) Hex Socket-Cylinder Head Cap Screw - DIN 912

Product Drawing

Socket Head Cap Screw Dimension Table (ISO4762/DIN912)
M Size Pitch (mm) Head Diameter (mm) Head Height (mm) Drive Size (mm)
M1.6 0.35 3.0 1.6 1.5
M2 0.40 3.8 2.0 1.5
M2.5 0.45 4.5 2.5 2.0
M3 0.50 5.5 3.0 2.5
M4 0.70 7.0 4.0 3.0
M5 0.80 8.5 5.0 4.0
M6 1.00 10.0 6.0 5.0
M8 1.25 13.0 8.0 6.0
M10 1.50 16.0 10.0 8.0
M12 1.75 18.0 12.0 10.0
M14 2.00 21.0 14.0 12.0
M16 2.00 24.0 16.0 14.0

Dimension Table

Dimensions for PEEK (GF30) Hex Socket-Cylinder Head Cap Screw - DIN 912 in all available sizes are shown according to the product drawing above.

Key Polyether Ether Ketone GF30 (PEEK GF30) - 30% Glass Fibre Reinforced Properties

Polyether Ether Ketone GF30 (PEEK GF30) - 30% Glass Fibre Reinforced Datasheet

Follow the link below to view our PEEK GF30 data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.

Download PDF

Custom Manufacturing

Can't find a component?

We can manufacture components to your specification in any of our performance polymer materials. Click on the link, fill out a short form and you'll receive a competitive, no obligation quote within 24 hours.

Request a Quote

PEEK GF30 Key Properties

  • Exceptional Tensile strength - PEEK GF30 components are reinforced with 30% glass-fibre. This provides all the desired unfilled PEEK characteristics as well as a vast increase in strength and stiffness. PEEK GF30 is a true metal replacement.

    Exceptional dimensional stability - Even at high temperatures (260°).

    Low Radio Frequency noise - Comparable to air.

    Excellent weight to strength ratio - Specific gravity (1.30).

  • - High heat operation (260°C)

    - Exceptional chemical resistance

    - Ultra low weight

    - Flame resistance

    - Abrasion resistance

    - Hydrolysis resistance

  • - Highly resistant to radiation

    - Non-Magnetic

    - Very low outgassing in high vacuum

    - Low thermal conductivity

    - Non-Corrosive

    - Food safe (FSA/FDA Approved)
