RENY Hexagon Nuts

76 in stock now, more available within 14 days.
SKU: RNYHNM3
Regular price £0.55 GBP / each
Regular price Sale £0.58 GBP Sale price £0.55 GBP

Instant Quote Guarantee:
Submit a request for quote online by clicking the button below and it'll be delivered to your inbox within 5 mins.

Request For Quote

Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom right of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080

RENY Hexagon Nuts

Product Drawing

Hexagon Nut Dimension Table (ISO 4032/DIN 934)
M Size Pitch (mm) Width (Flat-Flat) (mm) Thickness (mm)
M2 0.4 4.0 1.6
M2.6 0.45 5.0 2.0
M2.5 0.45 5.0 2.0
M3 0.5 5.5 2.4
M4 0.7 7.0 3.2
M5 0.8 8.0 4.0
M6 1.0 10.0 5.0
M8 1.25 13.0 6.5
M10 1.50 17.0 8.0
M12 1.75 19.0 10.0

Dimension Table

Dimensions for RENY Hexagon Nuts in all available sizes are shown according to the product drawing above.

RENY Countersunk Flat Head Screws - High Performance Polymer-Plastic Fastener Components

RENY (50% Glass Fibre Reinforced Nylon MXD6) Datasheet

Follow the link below to view our RENY data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.

Download PDF

RENY Key Properties

  • High Tensile Strength – RENY is among the highest performing polymer screws in terms of tensile strength on the market today (285Mpa).

    Low cost - In comparison to other engineered polymer, such as PPS, PI and PEEK.

    Low water absorption – especially when compared to Nylon 6/6, this allows dimensional stability and mechanical strength to remain high even under high water absorption environments.

    Excellent weight to strength ratio - Specific gravity (1.65).

  • - Non-Magnetic

    - Low thermal conductivity

    - Non-Corrosive

    - High heat operation (105°C)

    - Ultra low weight

  • - Flame resistance (UL94 HB)

    - Hydrolysis resistance

ISO 9001 Certified

Certified through Quality Veritas. High Performance Polymer conforms to the ISO9001 quality management system. Certificates available on request.

Certificate Of Conformity

Product certificate of conformity available on request, confirming the product manufacturing standard and material.

Material Certificates

Full material traceability and certification confirming the material data and raw material batch number, which can be traced back to the manufacturer.

Highly Competitive Prices

We offer price matching against all UK distrubutors. All of our products are manufactured to the highest standards and exhibit exceptional characteristics.
