PEEK Spacer Nuts
NEED HELP?

Our team are always happy to answer questions or provide advice.

Live Chat: Available from the bottom right of your screen.

Email: sales@highperformancepolymer.co.uk

Phone: 01865 684080

PEEK Spacer Nuts

PKSN304
  • Sale
  • £7.20 / each

Price excludes VAT

0 Available for express delivery.

PRICE MATCH PROMISE

HPP price match against all UK suppliers. Found it cheaper? Contact us and we will beat it!

REQUIRE A QUOTE?

Simply add the required product(s) to the shopping cart and select 'request for quotation'.

WORLDWIDE SHIPPING

We ship worldwide! Same day dispatch for all express products ordered before 3PM GMT.

PEEK Spacer Nut Dimensions:

(mm)M3M4M5M6M8
Thread Pitch
0.50.70.81.01.25
Flat to Flat (mm)
6.07.08.010.013.0

PEEK (POLYETHER ETHER KETONE)

Spacer Nuts

PEEK hexagonal spacer nuts are available for purchase directly from our website.

Our PEEK spacer nuts are perfect for spacing components such as PCB’s. They encompass the same characteristics as all our PEEK fasteners, which makes them perfect for use within extreme environments or applications.

It is important to note that not all the internals within the spacer nut are fully threaded depending on length. The thread portion spans twice the diameter in length from each end of the spacer. For example, in an M3 spacer nut the threads will span 6mm in length from each end of the nut (For an M3 spacer of 12mm or less in length the internals will be fully threaded).

If you have any questions, please don’t hesitate to contact us.

The spacer nuts can be torqued using a standard metric spanner or socket.

Key Properties of PEEK Spacer Nuts Include:

Exceptional chemical resistance
PEEK screws can only be dissolved in high concentrations of Nitric and Sulphuric acids.

Exceptional dimensional stability
Even at high temperatures (260°).

Low Radio Frequency noise
Comparable to air.

Excellent weight to strength ratio
Specific gravity (1.30).

  • High heat operation (260°C)
  • High tensile strength (97mpa)
  • Ultra low weight
  • Flame resistance
  • Abrasion resistance
  • Hydrolysis resistance
  • Highly resistant to radiation
  • Non-Magnetic
  • Very low outgassing
  • Low thermal conductivity
  • Non-Corrosive
  • Food safe (FSA/FDA Approved)

Exceptional chemical resistance
PEEK Spacer Nuts can only be dissolved in high concentrations of Nitric and Sulphuric acids.

Exceptional dimensional stability
Even at high temperatures (260°).

Low Radio Frequency noise
Comparable to air.

Excellent weight to strength ratio
Specific gravity (1.30).

  • High heat operation (260°C)
  • High tensile strength (97mpa)
  • Ultra low weight
  • Flame resistance
  • Abrasion resistance
  • Hydrolysis resistance
  • Highly resistant to radiation
  • Non-Magnetic
  • Very low outgassing in high vacuum
  • Low thermal conductivity
  • Non-Corrosive
  • Food safe (FSA/FDA Approved)
PEEK Data Sheet

Follow the link below to view our PEEK fastener data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.

View Data Sheet
