PEEK GF30 Hexagon Nut Dimensions:
(mm) | M2 | M3 | M4 | M5 |
---|---|---|---|---|
Pitch | 0.4 | 0.5 | 0.7 | 0.8 |
W | 2.1 | 3.2 | 4.3 | 5.3 |
T | 4.0 | 7.0 | 9.0 | 10.0 |

PEEK GF30 (30% GLASS-FIBRE REINFORCED POLYETHER ETHER KETONE)
Hexagon Nuts
30% Glass-fibre reinforced (GF30) PEEK Hexagon Nuts are an absolute necessity if chemical resistance and the ultimate in strength is required. Glass-fibre reinforcement helps to stiffen and strengthen PEEK hexagon nuts to ensure they function fully under the most demanding conditions possible.
Our PEEK GF30 Hexagon Nuts are complaint to with DIN 934 specification. We advise that our hexagon nuts are paired with PEEK GF30 Flat Washers to ensure no damage occurs to the fastener or the component when torquing.
Please call or email if you have any questions, HPP are here to provide solutions.
Key Properties of PEEK GF30 Hexagon Nuts Include:
Exceptional chemical resistance
PEEK screws can only be dissolved in high concentrations of Nitric and Sulphuric acids.
Exceptional dimensional stability
Even at high temperatures (260°).
Low Radio Frequency noise
Comparable to air.
Excellent weight to strength ratio
Specific gravity (1.30).
- High heat operation (260°C)
- High tensile strength (97mpa)
- Ultra low weight
- Flame resistance
- Abrasion resistance
- Hydrolysis resistance
- Highly resistant to radiation
-
Non-Magnetic
- Very low outgassing
- Low thermal conductivity
- Non-Corrosive
- Food safe (FSA/FDA Approved)
Exceptional Tensile Strength
PEEK GF30 hexagon nuts are reinforced with 30% glass-fibre. This provides all the desired PEEK characteristics as well as a vast increase in strength and stiffness. PEEK GF30 is a true metal replacement.
Exceptional dimensional stability
Even at high temperatures (260°).
Low Radio Frequency noise
Comparable to air.
Excellent weight to strength ratio
Specific gravity (1.30).
- High heat operation (260°C)
- High tensile strength (97mpa)
- Ultra low weight
- Flame resistance
- Abrasion resistance
- Hydrolysis resistance
- Highly resistant to radiation
-
Non-Magnetic
- Very low outgassing in high vacuum
- Low thermal conductivity
- Non-Corrosive
- Food safe (FSA/FDA Approved)
PEEK GF30 Data Sheet
Follow the link below to view our PEEK GF30 fastener data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.
View Data SheetCertificates Available On Request
