Imperial PEEK GF30 Pan Screw

Manufactured to order.
SKU: PKGFPNIMP256316
Regular price £1.04 - £1.60 GBP / each

Volume Discounts Available:

1 pc £1.60
20 pcs £1.52
50 pcs £1.44
100 pcs £1.28
250 pcs £1.20
500 pcs £1.12
1000 pcs £1.04
2000+ pcs Contact us
Show more Show less
Want it by XYZ?
Want it by XYZ?

Need Help?
Our team are always happy to help!
Live Chat: Available from the bottom left of your screen.
Email: sales@highperformancepolymer.com
Phone: +44(0)1865 684080

Instant Quote:
Submit a request for quote online by clicking the button below and a PDF quotation will be delivered to your inbox within 5 mins.

Request a Quote

Material: PEEK GF30

Measurement System: Imperial

Drive Type: Cross Recessed/Phillips

Natural

Continuous use temperature: 260°C/500°F

Flammability: UL94 V-0

Imperial PEEK GF30 Pan Screw conform to the following Standards/Norms:

Imperial PEEK GF30 Pan Screws, available in thread sizes ranging from 2-56 to 1/4-20 and lengths from 3/16" to 1", are made from Polyether Ether Ketone (PEEK) reinforced with 30% glass fibers. This combination creates a high-performance fastener with exceptional mechanical strength and rigidity. The pan head design allows for a secure, low-profile fastening, ideal for applications requiring durability and precision. PEEK GF30 is known for its high tensile strength, excellent thermal stability, and outstanding chemical resistance. These properties make Imperial PEEK GF30 Pan Screws suitable for use in demanding environments where reliability and long-lasting performance are critical.

Imperial Thread Size – 2-56, 4-40, 6-32, 8-32, 10-32, ¼-20

Length (In) – 3/16”, ¼”, 5/16’, 3/8”, ½”, 5/8”, ¾”, 7/8”, 1”

Advantages of Using Imperial PEEK GF30 Pan Screws:

Enhanced Mechanical Strength: The 30% glass fiber reinforcement significantly increases the tensile and compressive strength of the screws, providing robust and reliable fastening.

Thermal Stability: PEEK GF30 maintains its structural integrity and mechanical properties across a wide temperature range, making it suitable for both high-temperature and cryogenic environments.

Chemical Resistance: The material resists a wide variety of chemicals, including acids, bases, and solvents, ensuring durability in corrosive environments.

Electrical Insulation: PEEK GF30 offers excellent insulating properties, making these screws ideal for electronic and electrical applications.

Lightweight: Despite their high strength, PEEK GF30 screws are lightweight, reducing the overall weight of assemblies and facilitating easier handling.

Low Friction and Wear Resistance: The glass fiber reinforcement enhances the wear resistance and reduces friction, extending the lifespan of the screws and the components they secure.

Specific Applications of Imperial PEEK GF30 Pan Screws:

Aerospace:

Used in aircraft and spacecraft systems where lightweight, high-strength fasteners are essential for performance and safety.

Suitable for environments with extreme temperatures and exposure to radiation, such as satellites and space exploration equipment.

Chemical Processing:

Applied in securing components in chemical processing plants, where resistance to aggressive chemicals and high temperatures is crucial.

Ideal for use in reactors, pumps, and valves, providing reliable sealing and fastening.

Electronics and Electrical Equipment:

Used in the assembly of electronic devices and enclosures, where the screws' electrical insulation properties are beneficial.

Suitable for securing circuit boards, connectors, and sensitive electronic components.

Medical Devices:

Utilised in medical instruments and equipment, taking advantage of PEEK GF30's biocompatibility and resistance to repeated sterilisation processes.

Ideal for securing components in diagnostic and analytical equipment where precision and reliability are critical.

Automotive Industry:

Used in automotive applications, particularly in engine compartments and electronic systems, where high heat and chemical resistance are required.

Applied in the assembly of hybrid and electric vehicles, offering a lightweight, durable fastening solution.

Imperial PEEK GF30 Pan Screws, available in thread sizes from 2-56 to 1/4-20 and lengths from 3/16" to 1", offer a robust and reliable fastening solution made from glass fiber-reinforced Polyether Ether Ketone (PEEK). These screws are known for their exceptional mechanical strength, thermal stability, and chemical resistance, making them ideal for a variety of demanding applications across aerospace, chemical processing, electronics, medical devices, and automotive industries. The combination of durability, lightweight nature, and resistance to harsh conditions ensures that PEEK GF30 pan screws provide reliable and long-lasting performance in critical environments.

The PEEK GF30 data sheet is available as a PDF to download below.

Return components within 90 days for a full refund. Please see returns terms and conditions for further information.

Imperial PEEK GF30 Pan Screw

Product Drawing

Imperial PEEK GF30 Pan Screw Dimension Table
Thread Size Thread Series Head Diameter Head Height
2-56 UNC 0.167 0.058
4-40 UNC 0.219 0.080
6-32 UNC 0.270 0.097
8-32 UNC 0.322 0.115
10-24 UNC 0.373 0.113
10-32 UNF 0.373 0.113
1/4-20 UNC 0.492 0.175

Dimension Table

Dimensions for Imperial PEEK GF30 Pan Screw in all available sizes are shown according to the product drawing above.

Key Polyether Ether Ketone GF30 (PEEK GF30) - 30% Glass Fibre Reinforced Properties

Polyether Ether Ketone GF30 (PEEK GF30) - 30% Glass Fibre Reinforced Datasheet

Follow the link below to view our PEEK GF30 data sheet. This includes properties such as mechanical, electrical, thermal and chemical resistance.

Download PDF

Custom Manufacturing

Can't find a component?

We can manufacture components to your specification in any of our performance polymer materials. Click on the link, fill out a short form and you'll receive a competitive, no obligation quote within 24 hours.

Request a Quote

PEEK GF30 Key Properties

  • Exceptional Tensile strength - PEEK GF30 components are reinforced with 30% glass-fibre. This provides all the desired unfilled PEEK characteristics as well as a vast increase in strength and stiffness. PEEK GF30 is a true metal replacement.

    Exceptional dimensional stability - Even at high temperatures (260°).

    Low Radio Frequency noise - Comparable to air.

    Excellent weight to strength ratio - Specific gravity (1.30).

  • - High heat operation (260°C)

    - Exceptional chemical resistance

    - Ultra low weight

    - Flame resistance

    - Abrasion resistance

    - Hydrolysis resistance

  • - Highly resistant to radiation

    - Non-Magnetic

    - Very low outgassing in high vacuum

    - Low thermal conductivity

    - Non-Corrosive

    - Food safe (FSA/FDA Approved)
